FLIR E75sc/E85sc/E85sc

고성능 휴대 및 벤치타입 열화상 카메라 / 연구용 패키지




개요

  • FLIR E75sc, E85sc, E95sc 벤치탑키트 열화상 카메라를 사용하시면, 수천 개가 넘는 위치의 온도를 실시간으로 측정 하실 수 있으며 신뢰성 높은 데이터를 신속하게 얻을 수 있습니다. 또한 다양한 렌즈를 통해 여러가지 측정 시야각을 얻을 수 있습니다.

특징

  • MSX 열화상 화질 향상 기술
  • 디지털 실화상 카메라 탑재
  • FLIR Tools 모바일 커뮤니케이션
  • 자동 방향
  • 터치스크린 제어
  • 최대 161,472 픽셀 이미지
  • 25° 기본 렌즈
  • 접사렌즈(옵션)를 통해 공간분해능 50μm의 접사 측정 가능
  • ResearfhIR 소프트웨어를 통해 실시간 이미지 전송 및 온도그래프 생성 가능

사양



FLIR E75 24°
FLIR E85 24°
FLIR E95 24°
Infrared resolution320 × 240 pixels384 × 288 pixels464 × 348 pixels
UltraMax (super-resolution)In FLIR Tools
NETD• <30 mK, 42° @ +30°C (+86°F)
• <40 mK, 24° @ +30°C (+86°F)
• <50 mK, 14° @ +30°C (+86°F)
Field of view• 42° × 32°
• 24° × 18°
• 14° × 10°
Minimum focus distance• 0.15 m (0.49 ft.), 42°
• 0.15 m (0.49 ft.), 24°
• 1.0 m (3.28 ft.), 14°
Minimum focus distance with MSX• 0.65 m (2.13 ft.), 42°
• 0.5 m (1.64 ft.), 24°
• 1.0 m (3.28 ft.), 14°
Focal length• 10 mm (0.39 in.), 42°
• 17 mm (0.67 in.), 24°
• 29 mm (1.41 in.), 14°
Spatial resolution (IFOV)• 2.41 mrad/pixel, 42°
• 1.31 mrad/pixel, 24°
• 0.75 mrad/pixel, 14°
• 2.00 mrad/pixel, 42°
• 1.09 mrad/pixel, 24°
• 0.63 mrad/pixel, 14°
• 1.66 mrad/pixel, 42°
• 0.90 mrad/pixel, 24°
• 0.52 mrad/pixel, 14°
Additional lenses• 42°
• 14°
Lens identificationAutomatic
f number• 1.1, 42°
• 1.3, 24°
• 1.5, 14°
Image frequency30 Hz
Focus• Continuous LDM
• One-shot LDM
• One-shot contrast
• Manual
Field of view matchYes
Digital zoom1–4× continuous
Detector data
Focal plane array/spectral rangeUncooled microbolometer/7.5–14 µm
Detector pitch17 µm
Image presentation
Resolution640 × 480 pixels (VGA)
Surface brightness (cd/m2)400
Screen size4 in.
Viewing angle80°
Color depth (bits)24
Aspect ratio04:03:00 AM
Auto-rotationYes
TouchscreenOptically bonded PCAP
Display technologyIPS
Cover glass materialDragontrail®
Programmable buttons1
ViewfinderNo
Image adjustment• Automatic
• Automatic maximum
• Automatic minimum
• Manual
Image presentation modes
Infrared imageYes
Visual imageYes
Thermal fusionNo
MSXYes
Picture in PictureResizable and movable
GalleryYes


Measurement
Camera temperature rangeObject temperature rangeAccuracy — for ambient temperature +15 to +35°C (+59 to +95°F)
–20 to +120°C (–4 to +248°F)–20 to +100°C (–4 to +212°F)±2°C (±3.6°F)
+100 to +120°C (+212 to +248°F)±2%
0 to +650°C (+32 to +1202°F)0 to +100°C (+32 to +212°F)±2°C (±3.6°F)
+100 to + 650°C (+212 to +1202°F)±2%
Optional +300 to +1000°C (+572 to +1832°F)+300 to +1000°C (+572 to +1832°F)±2%


Measurement analysis
Spotmeter1 in live mode3 in live mode
Area1 in live mode3 in live mode
Automatic hot/cold detectionAuto-maximum/minimum markers within area
Measurement presets• No measurements
• Center spot
• Hot spot
• Cold spot
• User preset 1
• User preset 2
Difference temperatureYes
Reference temperatureYes
Emissivity correctionYes: variable from 0.01 to 1.0 or selected from materials list
Measurement correctionsYes
External optics/windows correctionYes
Screening0.5°C (0.9°F) accuracy @ 37°C (98.6°F) with reference
Alarm
Color alarm (isotherm)• Above
• Below
• Interval
• Condensation (moisture/humidity/dewpoint)
• Insulation
Measurement function alarmAudible/visual alarms (above/below) on any selected measurement function
Set-up
Color palettes• Iron
• Gray
• Rainbow
• Arctic
• Lava
• Rainbow HC
Setup commandsLocal adaptation of units, language, date and time formats
Languages21
Service functions
Camera software updateUse PC software FLIR Tools
Storage of images
Storage mediaRemovable memory; SD card (8 GB)
Time lapse (periodic image storage)No10 seconds to 24 hours (infrared)
Remote control operation• Using FLIR Tools (using USB cable)
• FLIR Tools Mobile (over Wi-Fi)
Image file formatStandard JPEG, measurement data included. Infrared-only mode
Image annotations
Voice60 seconds built-in microphone and speaker (and via Bluetooth) on still images and video
TextText from predefined list or soft keyboard on touchscreen
Visual image annotationYes
Image sketchYes: on infrared images only
SketchFrom touchscreen
METERLiNKWireless connection (Bluetooth) to:
FLIR meters with METERLiNK
CompassYes
Laser distance meter informationYes
Area measurement informationNoYes
GPSYes: location data automatically added to every still image and the first frame in video from built-in GPS
Video recording in camera
Radiometric infrared-video recordingRTRR (.csq)
Non-radiometric infrared-video recordingH.264 to memory card
Visual video recordingH.264 to memory card
Video streaming
Radiometric infrared–video streaming (compressed)Yes: over UVC or RTSP (Wi-Fi)
Non-radiometric video streaming (compressed: IR, MSX, visual, Picture in Picture)• H.264 (AVC) over RTSP (Wi-Fi)
• MPEG4 over RTSP (Wi-Fi)
• MJPEG over UVC and RTSP (Wi-Fi)
Visual video streamingYes
Digital camera
Resolution5 MP with LED light
FocusFixed
Field of view53° × 41°
Video lampBuilt-in LED light
Laser pointer
Laser alignmentPosition is automatically displayed on the infrared image
Laser distance meterActivated by a dedicated button
LaserClass 2, 0.05–40 m (1.6–131 ft.) ±1% of measured distance
Data communication interfaces
InterfacesUSB 2.0, Bluetooth, Wi-Fi, DisplayPort
METERLiNK/BluetoothCommunication with headset and external sensors
Wi-FiPeer to peer (ad hoc) or infrastructure (network)
AudioMicrophone and speaker for voice annotation of images
USBUSB Type-C: data transfer/video/power
USB standardUSB 2.0 High Speed
Video outDisplayPort
Video connector typeDisplayPort over USB Type-C
Radio
Operating frequencyBluetooth + EDR/LE: 2402–2480 MHz
WLAN 2.4 GHz: 2412–2462 MHz
WLAN 5 GHz: 5150–5350 MHz (DFS: only slave mode)
Note that frequency band 5150–5350 MHz is for indoor use only, see national regulations.
RF output (EIRP)Bluetooth + EDR/LE: < 10 dBm
WLAN: < 17 dBm
AntennaIntegrated PIFA antenna (gain: maximum 1.4 dBi)
Power system
Battery typeRechargeable Li-ion battery
Battery voltage3.6 V
Battery operating time> 2.5 hours at 25°C (68°F) and typical use
Charging systemIn camera (AC adapter or 12 V from a vehicle) or two-bay charger
Charging time (using two-bay charger)2.5 hours to 90% capacity with charging status indicated by LEDs
Charging temperature0°C to +‎45°C (+‎32°F to +‎113°F)‎, except for the Korean market: +10°C to +‎45°C (+‎50°F to +‎113°F)‎
External power operationAC adapter 90–260 V AC, 50/60 Hz, or 12 V from a vehicle (cable with standard plug—optional)
Power managementAutomatic shut-down and sleep mode
Environmental data
Operating temperature range–15 to +50°C (5–122°F)
Storage temperature range–40 to +70°C (–40 to +158°F)
Humidity (operating and storage)IEC 60068-2-30/24 hours/95% relative humidity 25–40°C (77–104°F)/two cycles
EMC• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (immunity)
• EN 61000-6-3 (emission)
• FCC 47 CFR Part 15 Class B (emission)
Radio spectrum• ETSI EN 300 328
• FCC Part 15.249
• RSS-247 Issue 2
EncapsulationIP 54 (IEC 60529)
Shock25g (IEC 60068-2-27)
Vibration2g (IEC 60068-2-6)
DropDesigned for 2 m (6.6 ft.)
SafetyEN/UL/CSA/PSE 60950-1
Physical data
Weight (including battery)1 kg (2.2 lb.)
Size (L × W × H)278.4 × 116.1 × 113.1 mm (11.0 × 4.6 × 4.4 in.)
Battery weight140 g (4.9 oz.)
Battery size (L × W × H)150 × 46 × 55 mm (5.9 × 1.8 × 2.2 in.)
Tripod mountingUNC ¼″-20
Housing materialPCABS with TPE, magnesium
ColorBlack
Warranty and service
Warrantyhttp://www.flir.com/warranty/
Shipping information
Packaging, typeCardboard box
Packaging, contents• Battery (2 ea)‎
• Battery charger
• Hard transport case
• Infrared camera with lens
• Lens cap,‎ front
• Lens cap,‎ front and rear (only for extra lenses)
• Accessory Box I: SD card (8 GB)‎ USB 2.0 A to USB Type-C cable,‎ 1.0 m USB Type-C to HDMI adapter,‎ standard specification UH311 USB Type-C to USB Type-C cable (USB 2.0 standard)‎,‎ 1.0 m Power supply for battery charger Power supply,‎ 15 W/3 A Printed documentation
• Accessory box II: Hand strap Lanyard strap,‎ camera Wrist strap Lens cap strap Front protection Carabiner hook Accessory box III: Hand strap bracket, right Hand strap bracket, left Torx T10 wrench Front protection fastener Screws
Packaging, weight5.8 kg (12.8 lb.)5.8 kg (12.8 lb.)5.8 kg (12.8 lb.)
